Trigno Load Cell Adapter

Monitor forces in virtually any circumstance

Instrument your lab with easy-to-use wireless load cell sensors that can be quickly affixed to equipment or worn by users to monitor forces in virtually any circumstance. Select from a catalog of strain gauge devices covering wide measurement ranges and available in several different designs.

Specifications
Quote Request
Trigno Load Cell Adapter

Supports a large variety of load cells

10g – 100Kg, S-type, Beam, Button style

Low, Medium & High Gain settings

Up to 40 m range

Specifications

User’s Guide

Sensor Channels
7

Analog Channels
1

Reference Type
N/A

Inter-Electrode Spacing
N/A

Size (Body)
27 x 46 x 13 mm

Size (Head)
N/A

Mass
19 g

Operating Range
40 m in RF mode
Host Dependent/unlimited datalogger

Wireless Protocol
-2.400-2.483 GHz ISM Band, Proprietary RF Protocol
-BLE V4.2

Analog Bandwidths
DC-50 Hz

(EMGworks) Analog Sampling Rate (Max)
2222 sa/sec

(EMGworks) Accelerometer Bandwidth (Max)
111 Hz

(EMGworks) Accelerometer Sampling Rate (Max)
370 sa/sec

(EMGworks) Gyroscope Bandwidth (Max)
152 Hz

(EMGworks) Gyroscope Sampling Rate (Max)
370 sa/sec

(EMGworks) Orientation Sampling Rate (Max)
74 sa/sec

Sensor Resolution
16 bits

Sensor Baseline Noise (typical)

Sensor Input Range
1.6mV / 3.3mV / 6.5mV

CMRR
< -100 dB

Battery Life
4 – 8 hours

Recharge Time (typical)
2.5 hours

Inter-Sensor Latency
< 1 sampling period

Digital Output Delay
Negligible

EMG Analog Output Delay
48 ms Fixed

ACC/Gyro Analog Output Delay
96 ms Fixed

Real-Time Signal Filter
Butterworth Low Pass (40 dB/Dec)

Real-Time IMU Orientation Filter
Quaternions or RPY (selectable)

Material
Medical Grade Polycarbonate

Seal and Protection
UV-sealed to prevent moisture from entering the sensor & to enhance patient safety

Patents
Protected by one or more of the following Patents 6480731, 6238338, 6440067, 9351559, 8971983, EP1070479

(API) EMG Bandwidth (Max)
50 Hz

(API) EMG Sampling Rate (Max)
2222 sa/sec

(API) Accelerometer Bandwidth (Max)
111 Hz

(API) Accelerometer Sampling Rate (Max)
370 sa/sec

(API) Gyroscope Bandwidth (Max)
152 Hz

(API) Gyroscope Sampling Rate (Max)
370 sa/sec

(API) Orientation Sampling Rate (Max)
74 sa/sec
